Multi-Functional Meeting Acoustic Pod

Product No.: PBD-SL-L

HK$55,800

	尺寸	2200(W)x1500(D)x2250(H)(mm)
	材料飾面	1. Sound insulation parameters: Design values RW+Ctr30dB (±5dB) and RT0.25 (±0.1s), sound insulation class NIC=32; 2. Cabin frame material: The four sides of the soundproof cabin are made of 6063-T5 refined aluminum alloy, with a wall thickness of 3-5mm. It is electrostatically sprayed with high-quality hydrogenated plastic resin powder, which is environmentally friendly, non-toxic, and odorless; 3. Cabin panel material: 50mm double-layer soundproof composite steel plate, internally compounded with multiple soundproof materials + 55kg polyester sound-absorbing cotton, meeting acoustic environmental indicators. The exterior steel plate surface is electrostatically sprayed with high-quality hydrogenated plastic resin powder; 4. Cabin glass material: 6mm+1.14pvd+4mm asymmetric laminated high-speed rail clear soundproof glass, with national 3C safety certification; 5. Cabin interior finish: 12mm high-density environmentally friendly polyester fiber sound-absorbing board, zero formaldehyde release, in accordance with inspection standards EN15012:2007+A1:2001 and EN12149:1997; 6. Cabin floor material: 5mm environmentally friendly nylon carpet + 50mm double-sided steel plate internally filled with fire-retardant composite soundproof material; 7. Door system configuration: 6mm+1.14pvd+4mm asymmetric laminated high-speed rail clear soundproof glass door, silent lock; 8. Environmental certification: Complies with GB/T18883-2002 indoor air quality standard SGS; 9. Smart lighting: Smart induction lighting system (default automatic, manual optional), LED light source 5000k with built-in constant current drive high-brightness chip, high-quality durable lamp beads, high-transparent Levi acrylic anti-glare mask, natural and soft light without glare; 10. Silent ventilation system: Smart induction exhaust, automatic ventilation, micro-positive pressure circulating air design; 11. Modular universal socket: Universal plug with USB TYPE-C interface; 12. Acoustic design: Sound insulation + buffering + vibration reduction + sound absorption acoustic design structure, multi-channel sound barrier weakens noise; 13. Environmental design: All components are environmentally friendly materials, zero formaldehyde release, environmentally friendly, non-toxic, and odorless; 14. Space design: Golden ratio design, ergonomic, making people feel no spatial oppression; 15. Sound effect design: Multi-channel sound barrier weakens noise, completely eliminates reverberation and humming in the space; 16. Expansion design: Standard modular design, realizing unlimited spatial expansion to meet different space needs; 17. Portable design: Fixed base at the bottom of the cabin, allowing the space to be moved with special tools; 18. Installation method: Modular installation, reusable. The outer frame connection uses steel-aluminum composite fasteners, and the cabin panel assembly is linked to the outer frame. On-site reinforcement is achieved through pre-drilled holes to improve efficiency, rejecting glue and nail gun structural configuration solutions. 19. Application scenarios: Consultation rooms, interview rooms, counseling rooms, reading rooms
	預算出貨時間	26-40 days

# 預算時間已包含送貨時間

Enjoy a one-time furniture delivery and installation service for orders over HK$12,000.

Product Introduction

The soundproof pod is meticulously crafted with sound insulation parameters that exceed industry standards, creating a robust sound barrier. It integrates a sophisticated acoustic design, combining double-layer composite steel plates, high-efficiency sound-absorbing cotton, and specially made soundproof glass to precisely attenuate noise and completely eliminate indoor reverberation. This ensures that every conversation is private, efficient, and crystal clear without any disturbance.

We understand the importance of health and sustainability. The soundproof pod uses an aerospace-grade 6063-T5 aluminum alloy frame and eco-friendly powder coating, along with zero-formaldehyde polyester fiber acoustic panels. It has also passed SGS indoor air quality certification. This ultimate commitment to the environment and health presents you with a pure, pollution-free green space.

The soundproof pod seamlessly integrates smart technology, featuring sensor-activated soft LED lighting and a slightly positive pressure circulation ventilation system to keep the air fresh and lighting comfortable at all times. Its golden ratio ergonomic space design eliminates any feeling of confinement; the modular structure allows for unlimited expansion and supports easy relocation, providing unprecedented flexibility and efficient convenience for your space.

More product images
