Spacious Office Acoustic Pod

Product No.: PBD-SL-M1

HK$72,000

	尺寸	1600(W)x1356(D)x2250(H)(mm)
	材料飾面	1. Sound insulation parameters: Design values RW+Ctr 30dB (±5dB) and RT 0.25 (±0.1s), sound insulation level NIC=32; 2. Cabin frame material: The four sides of the soundproof cabin are made of 6063-T5 refined aluminum alloy, with a wall thickness of 3-5mm. It is electrostatically sprayed with high-quality環氫塑脂 (likely a typo, perhaps "環氧樹酯" epoxy resin) powder, which is environmentally friendly, non-toxic, and odorless; 3. Cabin panel material: 50mm double-layer soundproof composite steel plate, with multiple layers of soundproof material + 55kg polyester sound-absorbing cotton inside, achieving acoustic environment indicators. The exterior steel plate surface is electrostatically sprayed with high-quality環氫塑脂 (epoxy resin) powder; 4. Cabin glass material: 6mm+1.14PVB+4mm asymmetric laminated high-speed rail plain white soundproof glass, with national 3C safety certification; 5. Cabin interior finish: 12mm high-density environmentally friendly polyester fiber acoustic panel, zero formaldehyde emission, inspected according to EN15012:2007+A1:2001 and EN12149:1997 standards; 6. Cabin floor material: 5mm environmentally friendly nylon carpet + 50mm double-sided steel plate internally filled with flame-retardant composite soundproof material; 7. Door system configuration: 6mm+1.14PVB+4mm asymmetric laminated high-speed rail plain white soundproof glass door, silent door lock; 8. Environmental certification: Complies with GB/T18883-2002 indoor air quality standard SGS; 9. Smart lighting: Smart sensing lighting system (default automatic, optional manual), LED light source 5000k with built-in constant current drive high-brightness chip, high-quality durable lamp beads, high-transparency Levi acrylic anti-glare mask, natural and soft light that is not dazzling; 10. Silent ventilation system: Smart sensing exhaust, automatic ventilation, micro-positive pressure circulating air design; 11. Modular universal socket: Universal plug with USB TYPE-C interface; 12. Acoustic design: Sound insulation + buffering + vibration reduction + sound absorption acoustic design structure, multi-channel sound barrier to attenuate noise; 13. Environmental design: All components are environmentally friendly materials, zero formaldehyde emission, environmentally friendly, non-toxic, and odorless; 14. Space design: Golden ratio design, ergonomic, ensuring no sense of spatial oppression; 15. Sound effect design: Multi-channel sound barrier to attenuate noise, completely eliminating reverberation and humming inside the space; 16. Expansion design: Standard modular design, allowing for infinite spatial expansion to meet different space requirements; 17. Portable design: Fixed base at the bottom of the cabin, allowing for movement of spatial position with special tools; 18. Installation method: Modular installation, reusable. The outer frame is connected with steel-aluminum composite fasteners. The cabin panels are assembled and linked to the outer frame, with pre-drilled holes for on-site reinforcement to improve efficiency, rejecting glue and shot nail structural configuration schemes. 19. Application scenarios: Consultation rooms, interview rooms, counseling rooms, reading rooms
	預算出貨時間	16-25 days

# 預算時間已包含送貨時間

Enjoy a one-time furniture delivery and installation service for orders over HK$12,000.

Product Introduction

Our spacious office acoustic pods utilize innovative acoustic engineering to create an unparalleled quiet space. With excellent sound insulation parameters boasting a designed value of RW+Ctr30dB, combined with 50mm double-layered soundproof composite steel panels and multiple sound-absorbing materials, external noise is completely isolated. Specially selected 6mm+1.14pvd+4mm asymmetrical laminated high-transparency low-iron soundproof glass ensures private, undisturbed conversations and contemplation, allowing you to focus on every important moment.

The acoustic pods also integrate cutting-edge intelligence and environmental concepts. The built-in smart sensor lighting system and micro-positive pressure circulation ventilation system automatically adjust comfortable lighting and fresh air, ensuring you feel exceptionally comfortable within. All components are carefully selected from environmentally friendly, non-toxic materials, meeting zero formaldehyde emission standards and SGS certification. Additionally, they are equipped with modular universal sockets and USB Type-C ports, showcasing the thoughtful integration of modern technology and a commitment to sustainability.

The spacious office acoustic pods are meticulously designed with the golden ratio, perfectly conforming to ergonomics, creating an open yet unconfined and comfortable experience. Their standard modular design not only allows for limitless expansion as needed but also features a fixed base that can be easily moved with specialized tools, achieving ultimate flexibility in space configuration and ensuring adaptability to changing business layouts.
