多人協作影音會議靜音艙 Team Collaboration Multimedia Meeting Pod

多人協作影音會議靜音艙 Team Collaboration Multimedia Meeting Pod

Product No.: PBD-SL-XL

HK$68,500

	尺寸	2470(W)x2380(D)x2250(H)(mm)
	材料飾面	1. Sound Insulation Parameters: Design values RW+Ctr30dB (±5dB) and RT0.25 (±0.1s), sound insulation level NIC=32; 2. Cabin Frame Material: The four sides of the soundproof cabin are made of 6063-T5 refined aluminum alloy, with a wall thickness of 3-5mm. It is electrostatically sprayed with high-quality環氫塑脂 (environmentally friendly hydrogen plastic resin) powder, which is environmentally friendly, non-toxic, and odorless; 3. Cabin Panel Material: 50mm double-layer soundproof composite steel plate, internally compounded with multiple sound insulation materials + 55kg polyester sound-absorbing cotton, achieving acoustic environmental indicators. The exterior steel plate surface is electrostatically sprayed with high-quality環氫塑脂 (environmentally friendly hydrogen plastic resin) powder; 4. Cabin Glass Material: 6mm+1.14pvd+4mm asymmetrical laminated high-speed rail plain white soundproof glass, with national 3C safety certification; 5. Cabin Interior Finish: 12mm high-density environmentally friendly polyester fiber sound-absorbing board, zero formaldehyde release, inspected according to EN15012: 2007+A1: 2001 and EN12149: 1997 standards; 6. Cabin Floor Material: 5mm environmentally friendly nylon carpet + 50mm double-sided steel plate internally filled with flame-retardant composite sound insulation material; 7. Door System Configuration: 6mm+1.14pvd+4mm asymmetrical laminated high-speed rail plain white soundproof glass door, silent door lock; 8. Environmental Certification: Complies with GB/T18883-2002 indoor air quality standard SGS; 9. Smart Lighting: Smart sensor lighting system (default automatic, optional manual), LED light source 5000k with built-in constant current drive high-brightness crystal chips, high-quality durable lamp beads, high-transparency Levia acrylic anti-glare mask, natural and soft light that is not dazzling; 10. Silent Ventilation System: Smart sensor exhaust, automatic ventilation, micro-positive pressure circulating air design; 11. Modular Universal Socket: Universal plug with USB TYPE-C interface; 12. Acoustic Design: Sound insulation + buffering + shock absorption + sound absorption acoustic design structure, multi-channel sound barrier to attenuate noise; 13. Environmental Design: All components are made of environmentally friendly materials, with zero formaldehyde release, environmentally friendly, non-toxic, and odorless; 14. Space Design: Golden ratio design, ergonomic, preventing a sense of spatial oppression; 15. Sound Effect Design: Multi-channel sound barrier to attenuate noise, completely eliminating reverberation and humming in the space; 16. Expansion Design: Standard modular design, allowing for infinite spatial expansion to meet different space requirements; 17. Portable Design: Fixed base at the bottom of the cabin, allowing for relocation with specialized tools; 18. Installation Method: Modular installation, reusable. The outer frame is connected with steel-aluminum composite fasteners, and the cabin panels are assembled and linked to the outer frame. On-site reinforcement is achieved through pre-drilled holes to improve efficiency, rejecting glue and nail gun structural solutions. 19. Application Scenarios: Meeting rooms, consulting rooms, interview rooms, live broadcast rooms, instrument rooms
	預算出貨時間	26-40 days

# 預算時間已包含送貨時間

Enjoy a one-time furniture delivery and installation service for orders over HK$12,000.

Product Introduction

This multi-person collaborative video conferencing soundproof booth features ingenious acoustic design, achieving extraordinary sound insulation performance. With outstanding performance of RW+Ctr30dB (±5dB) and RT0.25 (±0.1s), the sound insulation level reaches NIC=32, ensuring absolute privacy for conversations inside the booth. It employs 50mm double-layer soundproof composite steel panels, multiple soundproofing materials, and 55kg polyester sound-absorbing cotton, combined with national 3C certified 6mm+1.14pvd+4mm asymmetric laminated high-speed rail clear soundproof glass, effectively eliminating external noise and creating a truly quiet communication environment.

The smart-sensing lighting system provides a soft 5000K LED light source that is easy on the eyes; while the smart-sensing exhaust system with slightly positive pressure circulation ensures fresh air inside the booth at all times. It is equipped with universal sockets and USB Type-C ports to power your digital devices at any time, plus an ergonomic golden ratio space design that eliminates any sense of confinement, making every collaboration smooth and comfortable.

The booth frame is cast from 6063-T5 refined aluminum alloy, electrostatically sprayed with environmental epoxy resin powder, making it eco-friendly and non-toxic. The 50mm double-sided steel panels are filled with flame-retardant composite sound insulation material, the floor is covered with 5mm environmentally friendly nylon carpet, and 12mm high-density environmentally friendly polyester fiber sound-absorbing panels. All components meet strict environmental certification standards, achieving zero formaldehyde emission.

More product images
